Mastering the Sound of the Acoustic Guitar. Giuliano Nicoletti
Ref: 15227
En stock
Mastering The Sound Of The Acoustic Guitar Ever wondered how to measure the sound of the guitars you build ? How to shape its sound signature, with a simple method? How to choose the best tone wood for your project, or to solve problems of resonances, or wolf notes ?Mastering the sound of the acoustic guitar is a workshop manual written for guitar makers, that explains how the acoustic guitar works, how to shape the sound it produces and how to measure it in a simple and repeatable way. From tone wood technical evaluation and selection to fine tuning the performances of the instrument during the build or troubleshooting acoustic problems of a finished instrument, such as wolf tones. complete package of calculation and simulation tools is available for download , together with the database of the numerous measurements that illustrates each step.both for guitar makers and repair-maintenance shops , with 160 pages of beautifully color printed photos, illustrations, and graphics. Zach Lefebvre, Treehouse Guitars
“For those wanting to understand the dynamics of a coupled acoustic system, take measurements, and realize useful data (mechanical and acoustic) in order to craft better guitars, this manual will greatly accelerate and demystify the process. It distills the concepts into easily understandable tasks. Of course, it is not a substitute for empirical experience, and ultimately, doing the work. I wish this book had been written 30 years ago…”Michael Greenfield, Greenfield Guitars
Characteristics
Author: Giuliano Nicoletti
VIDEO
Reference
15227
In stock
9 Items
Data sheet
Type of Work: Instrument Building
